| Modelo | HW-190S |
| Profundidad de perforación (m) | 190 |
| Diámetro del orificio de salida (mm) | 500 (Suelo), 220 (Rocas) |
| Diámetro del orificio final (mm) | 75 |
| Diámetro de la barra de perforación (mm) | 42, 50 |
| Ángulo de perforación (ángulo) | 90-75 |
| Potencia (kW) | 13.2 |
| Peso (kg) | 2800 |
| Dimensiones (L*A*H) (m) | 4*1. 7*2. 3 |
Main feature:
1. Adopt hydraulic automatic drilling mechanism to improve drilling efficiency and reduce labor intensity;
2. Hengwang well drilling equipment is specially designed for the perfect match between the engine and the hydraulic system, which improves performance and reduces fuel consumption by 7%;
3. The fuselage design is compact and lightweight, which can work in plains and mountainous areas with less damage to vegetation.
Remark:
This product is continuously improved as technology advances. The difference between the parameters and the actual product is subject to the actual product.
Submit the form for more parameters and quotes.
